ISTI Poster @ EGU 8 – 13 April

ISTI is pleased to announce that Comparison of Detection and Location Capabilities of Surface Microseismic Monitoring Algorithms, by ISTI authors, will be presented at the European Geosciences Union General Assembly, being held in Vienna, Austria on 8–13 April 2018.

Authors: Ilya Dricker, Paul Friberg, Sidney Hellman

Date: Thu, 12 Apr

Time: 17:30–19:00

Location: Hall X2, X2.382

Abstract

The challenge of the surface microseismic monitoring (MSM) is that small-scale seismic activity which occurs as a result of human activities or industrial processes is often hidden in surface noise on individual seismic records. MSM algorithms must detect and locate signals with average signal-to-noise ratio (SNR) significantly less than 1. To improve SNR MSM algorithms compute cost function over a large set of seismic records. Maximum of such function indicates presence, time, and location of the seismic signal. Other algorithms, such as Phase Robust Statistically Optimal and Diagonal Maximum Likelihood Adaptive algorithms offer accuracy improvements of location and detection in presence of correlated industrial noise. In this paper we use synthetic seismograms and seismic observation to compare accuracy of event locations using several algorithms of surface microseismic monitoring.

ISTI’s Rapid Notification Service in Oklahoma helps Operators meet new Oklahoma Hydraulic Fracturing Regulations that Require Seismic Monitoring

On February 27, 2018, the Oklahoma Corporation Commission (OCC) announced new seismic monitoring requirements for minimizing felt induced seismicity from hydraulic fracturing operations in the SCOOP/STACK play. The new requirements state that operators must have access to a seismic monitoring array.  They must take action at magnitue 2.0 (Richter scale) and pause for 6 hours at magnitude 2.5. This is a 0.5 reduction in magnitude levels from previous regulations.

News articles in Oil Price, Reuters, and Bloomberg News and in local Oklahoma media outlets KFOR, Tulsa World, and The Oklahoman are already reporting that operators are taking the new regulations seriously and are installing private networks like those installed and operated by ISTI and it’s partners (HMSC, Inc and GEObit). ISTI can help operators in this region with our real-time monitoring networks for the duration of their completions or for an entire field-wide view using our Rapid Notification Service (RNS) product. ISTI’s Oklahoma and Kansas subscription based RNS provides operators with the information to act before regulators react to any events that may be caused by their completion operations.  An example is a recent 2.1 magnitude earthquake; subscribers were notified within 2 minutes after it occurred (see event map with locating stations below). As a result of the rapid information, nearby operators could modify their well treatment plans for the next stages and attempt to mitigate further larger events.

The cost of being shut-down temporarily for any nuisance earthquakes can be quite high for operators. Rapid information provided by ISTI’s service can allow operators to take action before being required to pause or curtail operations. While the hazard of earthquakes induced by hydraulic fracturing is low, there is still the potential for it to trigger larger felt earthquakes as has been observed in Canada. Operators, on the other hand, can mitigate impact to their businesses by taking proper precautions.

ISTI & GFAST in Chilean News

Both Ben Baker of ISTI and GFAST were highlighted in El Mercurio newspaper on 6 February 2018 in the Chile aplicara sistema para agilizar alerta temprana de maremotos y terremotos article (loosely translated, Chile will apply system to streamline early warning of tsunamis and earthquakes).

Overview

An inherent difficulty in seismic-only earthquake early warning and tsunami forecasting is the rapid estimation of the earthquake magnitude and description of the rupture.  One novel approach is to augment the seismic-base system with geodetic information that can better capture the static-offset produced during large events.  In conjunction with the University of Washington, the Amazon Catalyst program, and the Centro Sismológico Nacional, ISTI is helping to make the Geodetic First Approximation of Size and Timing (G-FAST) production ready in the dynamic Chilean tectonic setting.   It is expected that the G-FAST enhanced Earthworm+Earlybird base system will be able to better characterize the frequent high-magnitude events on the Chilean subduction zone and ultimately improve rapid shaking and tsunami inundation estimates.

Announcing Article: “G‐FAST Earthquake Early Warning Potential for Great Earthquakes in Chile”

ISTI is pleased to announce a publication of G‐FAST Earthquake Early Warning Potential for Great Earthquakes in Chile, a collaboration between Ben Baker of ISTI and our colleagues in the field.  The article was published by SSA (the Seismological Society of America) and posted to GeoScience World on 7 February 2018.  ISTI wishes to recognize the authors:

  • Brendan W. Crowell – Department of Earth and Space Sciences, University of Washington
  • David A. Schmidt – Department of Earth and Space Sciences, University of Washington
  • Paul Bodin – Department of Earth and Space Sciences, University of Washington
  • John E. Vidale –  Department of Earth and Space Sciences, University of Washington
  • Ben Baker – (ISTI) Instrumental Software Technologies, Inc.
  • Sergio Barrientos – Centro Sismológico Nacional, Universidad de Chile
  • Jianghui Geng – GNSS Research Center, Wuhan University

The abstract may be read here.





Oklahoma hydraulic fracturing induced earthquakes in the news

A recent Bloomberg news article on increasing earthquakes in the Oklahoma SCOOP/STACK play is stating that regulators and the Oil and Gas industry are starting to turn their attention to monitoring hydraulic fracture induced earthquakes that are reportedly being felt in this region. While the predominant cause of induced earthquakes in Oklahoma have been tied to injection of produced waste water, hydraulic fracturing related earthquakes has received less attention until now. The Oklahoma Corporation Commission, which governs oil and gas wells in the state, was anticipating this back at the end of 2016 when they released guidelines that governed seismic concerns in this play. These regulations and the recent uptick in activity in this area suggest that monitoring for induced seismicity, like that done by ISTI, would be of great cost benefit to operators in the area so that they have operational information to head-off potential regulatory action.

Note that a similar news article was published in Bloomberg about hydraulic fracture induced earthquake concerns in Alberta Canada in the town of Fox Creek, where larger felt earthquakes have occurred in recent years.

Announcing Article: “Maturity of nearby faults influences seismic hazard from hydraulic fracturing”

ISTI is pleased to announce a publication of Maturity of nearby faults influences seismic hazard from hydraulic fracturing, a collaboration between ISTI and our colleagues in the field.  The article was published by the National Academy of Sciences on 5 February 2018.  ISTI wishes to recognize the authors:

  • Maria Kozłowska – Department of Geology and Environmental Earth Science, Miami University, Oxford, OH
  • Michael R. Brudzinski – Department of Geology and Environmental Earth Science, Miami University, Oxford, OH
  • Paul Friberg – (ISTI) Instrumental Software Technologies, Inc.
  • Robert J. Skoumal – Earthquake Science Center, US Geological Survey
  • Nicholas D. Baxter – Department of Geology and Environmental Earth Science, Miami University, Oxford, OH
  • Brian S. Currie – Department of Geology and Environmental Earth Science, Miami University, Oxford, OH



Excerpt, courtesy of PNAS

Significance

Recent studies have focused on how wastewater disposal wells have caused dramatic increases in eastern US earthquakes. We focused instead on less common cases where hydraulic fracturing alone has caused earthquakes and found seismicity separated into two depth zones: a shallow zone on younger faults, with more small-magnitude earthquakes than expected, and a deeper zone on older faults, with larger magnitude earthquakes and seismicity continuing after fracturing stops. Hence, inducing deeper seismicity creates more hazard. Our observations are consistent with prior geologic, laboratory, and theoretical work indicating that age and maturity of faults causes the different seismicity patterns. We utilize data from well operators to demonstrate that both fluid pressure changes and rock stress transfer are needed to explain our observations.

Abstract

Understanding the causes of human-induced earthquakes is paramount to reducing societal risk. We investigated five cases of seismicity associated with hydraulic fracturing (HF) in Ohio since 2013 that, because of their isolation from other injection activities, provide an ideal setting for studying the relations between high-pressure injection and earthquakes. Our analysis revealed two distinct groups: continue reading.

Additional News

The above article was also referenced in the Pittsburgh Post Gazette. The above article was also referenced on NPR’s WESA in the Pittsburgh area.

Additional ISTI abstract:

ISTI will be presenting at the European Geosciences Union General Assembly, being held in Vienna, Austria on 8–13 April 2018.  Read more here.

ISTI @ AGU 11 – 15 December

ISTI, Geobit, and HMSCInc join together at the AGU Annual Meeting in New Orleans, Louisiana next week.  We are a team providing a complete seismic monitoring solution. Contact us through EarthImaging.com.



With 65+ years of combined experience, GEObit, HMSCInc and ISTI are joining forces to become the most competitive and fastest growing joint venture group in the seismic monitoring services industry.

Providing state-of-the-art seismic instruments, network design, installation techniques, data monitoring and processing services, our group is able to deliver a cost-effective total solution to the energy exploration & production industry, especially to the oil, gas and geothermal sector. Our key benefits are that we produce in-house hardware and software while installing and maintaining the microseismic monitoring network to ensure a high level of data quality and availability. In other words, we make the technology – we apply the technology – we offer the technology.

Geobit Digitizer. Photo, courtesy of Geobit.

We have worldwide experience having installed and operated seismic networks all over the world, from Indonesia/Papua jungle to the Middle East desert, from Alaska glaciers to

Himalayan Mountains. In the USA, we are currently running many dedicated microseismic monitoring projects with over 200 stations installed in the past 10 years.



Visit us at booth #1939, AGU 2018

New Orleans, Louisiana USA  |  11 – 15 December

Meet our team and learn about the latest offerings. Dimitris Mourtzouchos & Nikos Germenis (Geobit), Mike Hasting (HMSCInc.), Paul Friberg & Sid Hellman (ISTI), and others will be available to answer your questions.

Stefan Lisowski (middle) and Ben Baker (right) of ISTI with visitor. Photo, courtesy of Geobit, AGU 2018.

Geobit Instruments Ltd.

Data Loggers and Sensors, Visit the website



GEObit provides high sensitivity wide-band and near broadband seismic sensors, surface or borehole type, and high dynamic range, low power 32bit ADC data loggers with local data storage and real time telemetry over seedlink protocol. We are focusing on low power and cost effective solutions so we provide to our customer seismic networks with low installation and maintenance costs. Our instruments are ideal for local and regional seismicity and micro-seismicity monitoring and for seismic events such as those induced by unconventional hydrocarbon extraction. Our high fidelity data-loggers ensure that these signals are recorded with the highest resolution and timing accuracy.



Hasting Micro-Seismic Consulting, Inc (HMSCInc)

Installation and Operations, Visit the website

HMSCInc has over 30 years’ experience designing, building and installing dedicated microseismic monitoring stations and networks for seismicity monitoring of active geothermal resources, oil and gas fields, and volcanoes. HMSCInc provides integrated seismic station solutions, pre-drilling background monitoring services, installation of borehole stations (from a few hundred feet to over 10,000 ft), real-time event detection and location services, as well as expert testimony when needed.


Instrumental Software Technologies, Inc. (ISTI)

Monitoring and Data Processing, ISTI.com home page



ISTI specializes in developing custom data acquisition, analysis, and processing software for the geophysical sciences. Microseismic data acquisition and processing are performed by custom solutions using existing open source software as a foundation, saving our customers both time and money. ISTI provides several products and services covering all geophysical applications and monitoring needs of the industry.

Nikos Germenis (Geobit) & Sid Hellman (ISTI) @ Earth Imaging booth, AGU 2018, New Orleans. Photo, courtesy of Geobit.

(from left to right) Ben Baker (ISTI), Dimitris Mourtzouchos & Nikos Germenis (Geobit). Photo, courtesy of Geobit.

Susan & Mike Hasting (HMSCInc.). Photo, courtesy of Geobit.

ISTI Presents at AGU in New Orleans, December 2017

ISTI is presenting at the AGU Fall Meeting being held in New Orleans, 11-15 December 2017. In addition, ISTI welcomes you to visit our team at our AGU exhibit throughout the week.



View the ISTI poster schedule and abstract links below.



Author
Abstract
Date
Time
Location
Paul A Friberg (w/ Miami University Oxford presenters) S14A-05: Two types of seismicity accompanying hydraulic fracturing in Harrison County, Ohio – implications for seismic hazard and seismogenic mechanism Monday, 11 Dec. 17:00 – 17:15 217-219
Paul Friberg, Ilya Dricker (w/  Miami University Oxford and Cedarville University presenters) Tuesday, 12 Dec. 13:40 – 18:00 Poster Hall D-F
Stefan Lisowski, Paul Friberg (w/ Chonnam National University presenter) Monday, 11 Dec. 13:40 – 18:00 Poster Hall D-F
Kevin Frechette (w/ IRIS presenters) Thursday, 14 Dec. 16:21 – 16:24 eLightning Area
Ben Baker Tuesday, 12 Dec. 08:00 – 12:20 Poster Hall D-F
Josh Stachnick (w/ JAMSTEC and CTBTO presenters) Monday, 11 Dec. 13:40 – 18:00 Poster Hall D-F
Josh Stachnick (w/ Lehigh University, Brown University, Institute of Astronomy & Geophysics, and University of Florida presenters) Tuesday, 12 Dec. 13:40 – 18:00 Poster Hall D-F
Josh Stachnick, Ben Baker, Paul Friberg,  Jeffrey Leifer (w/ CTBTO presenter) Thursday, 14 Dec. 08:00 – 12:20 Poster Hall D-F





ISTI’s Josh Stachnik will be representing Lehigh University in the following posters.

View the Josh’s Lehigh poster schedule and abstract links below.

Author
Abstract
Date
Time
Location
Josh Stachnick (w/ Lehigh University, University of Florida, and Institute of Astronomy & Geophysics presenters) Tuesday, 12 Dec. 13:40 – 18:00 Poster Hall D-F
Josh Stachnick (w/ University of Colorado, Washington University, USGS, and University of Florida presenters) Monday, 11 Dec 15:10 – 15:25 215-216
Josh Stachnick (w/ University of Arizona, University of Texas, Lehigh University, Instituto Geofísico EPN, University of Liverpool, and Géoazur presenters) Wednesday, 13 Dec 11:20 – 11:35 211-213
Josh Stachnick (w/ Lehigh University, USGS, Géoazur, Instituto Geofísico EPN, University of Arizona, Global Seismological Services, and University of Liverpool presenters) Friday, 15 Dec. 13:40 – 18:00 Poster Hall D-F
Josh Stachnick (w/ Géoazur, CEREMA, University of Liverpool, Instituto Geofísico EPN, University of Arizona, and Lehigh University presenters) Friday, 15 Dec. 13:40 – 18:00 Poster Hall D-F



AGU Fall Meeting in New Orleans

What’s this meeting all about? Check out this short video.

Video Courtesy of American Geophysical Union (AGU)..

ISTI @ SEG 24 – 29 September

ISTI, HMSC, and Geobit join together at the SEG Annual Meeting in Houston, Texas this September.  We are a team providing a complete seismic monitoring solution. Contact us through EarthImaging.com.

First and foremost, our thoughts go out to those impacted by the Houston flood.  As SEG writes:

Houston is dear to our hearts, and SEG wants to do everything it can to support the city while advancing the interests and needs of our members, attendees, sponsors, exhibitors, and presenters. . . . Officials with the George R. Brown Convention Center and the City of Houston have assured SEG that the city is ready to accommodate Annual Meeting participants. SEG staff members and volunteer leaders have inspected the Conference Center, supporting hotels, and venues, and agree that Houston is open for business!

Read more about what SEG is doing to prepare for conference goers and support the local community.

With 65+ years of combined experience, GEObit, HMSCinc and ISTI are joining forces to become the most competitive and fastest growing joint venture group in the seismic monitoring services industry.

Providing state-of-the-art seismic instruments, network design, installation techniques, data monitoring and processing services, our group is able to deliver a cost effective total solution to the energy exploration & production industry, especially to the oil, gas and geothermal sector. Our key benefits are that we produce in-house hardware and software while installing and maintaining the microseismic monitoring network to ensure a high level of data quality and availability. In other words, we make the technology – we apply the technology – we offer the technology.

We have worldwide experience having installed and operated seismic networks all over the world, from Indonesia/Papua jungle to the Middle East desert, from Alaska glaciers to Himalayan Mountains. In the USA, we are currently running many dedicated microseismic monitoring projects with over 200 stations installed in the past 10 years.



Visit us at booth #2521, SEG2017

Houston Texas, USA  |  24 – 29 September 2017

Meet our team and learn about the latest offerings. Dimitris Mourtzouchos & Nikos Germenis (Geobit), Mike Hasting (HMSC, Inc.), and Paul Friberg & Ilya Driker (ISTI) will be available to answer your questions.

Again, SEG advises that Houston is open for business.





Geobit Instruments Ltd.

Data Loggers and Sensors, Visit the website



GEObit provides high sensitivity wide-band and near broadband seismic sensors, surface or borehole type, and high dynamic range, low power 32bit ADC data loggers with local data storage and real time telemetry over seedlink protocol. We are focusing on low power and cost effective solutions so we provide to our customer seismic networks with low installation and maintenance costs. Our instruments are ideal for local and regional seismicity and micro-seismicity monitoring and for seismic events such as those induced by unconventional hydrocarbon extraction. Our high fidelity data-loggers ensure that these signals are recorded with the highest resolution and timing accuracy.



Hasting Micro-Seismic Consulting, Inc (HMSCinc)

Installation and Operations, Visit the website



HMSCinc has over 30 years’ experience designing, building and installing dedicated microseismic monitoring stations and networks for seismicity monitoring of active geothermal resources, oil and gas fields, and volcanoes. HMSCinc provides integrated seismic station solutions, pre-drilling background monitoring services, installation of borehole stations (from a few hundred feet to over 10,000 ft), real-time event detection and location services, as well as expert testimony when needed.


Instrumental Software Technologies, Inc. (ISTI)

Monitoring and Data Processing, ISTI.com home page



ISTI specializes in developing custom data acquisition, analysis, and processing software for the geophysical sciences. Microseismic data acquisition and processing are performed by custom solutions using existing open source software as a foundation, saving our customers both time and money. ISTI provides several products and services covering all geophysical applications and monitoring needs of the industry.
